Descripción del Producto
This 2020 Sumitomo SH130-5 hydraulic excavator represents a cost-effective solution for mid-size earthmoving operations. Currently located in Zhejiang, China, this machine offers proven reliability from Sumitomo's well-regarded construction equipment lineup.
The SH130-5 series is engineered for versatility across construction, utility, and landscaping applications. With its 13-ton operating class, this excavator delivers balanced performance for trenching, grading, and material handling tasks.
- Year of Manufacture: 2020
- Model: Sumitomo SH130-5
- Location: Zhejiang Province, China
- Competitive pricing for the Asian market
- Suitable for contractors seeking reliable used equipment
This unit presents an opportunity for businesses requiring dependable excavation equipment with established Japanese engineering standards. Contact us for detailed inspection reports, shipping arrangements, and current availability.
| Especificaciones | Valor |
|---|---|
| No. | 1114415 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12500 |
| Bucket capacity (m³) | 0.55 |
| Boom length (mm) | 4630 |
| Rod length (mm) | 2500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 70.9//2000 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 40 |
| Rotation speed (rpm) | 14.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 90 |
| Rod digging force (kN) | 62 |
| Travel speed (km/h) | 3.4/5.6 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 82 |
| Hydraulic System (L) | 157 |
| Total transport length (mm) | 7620 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 2820 |
| Full cab height (mm) | 2820 |
| Counterweight ground clearance (mm) | 895 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 2340 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3500 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Maximum digging radius (mm) | 8320 |
| Maximum digging depth (mm) | 5550 |
| Maximum excavation height (mm) | 8780 |
| Maximum unloading height (mm) | 6380 |
| Maximum vertical digging depth (mm) | 4960 |
