Descripción del Producto
Esta excavadora Volvo EC480D de 2014 representa una oportunidad sólida para los contratistas que buscan un rendimiento comprobado en una máquina de trabajo pesado. Ubicada en Shandong, China, esta unidad proviene de la respetada línea Serie D de Volvo, reconocida por su eficiencia de combustible y la comodidad del operador en aplicaciones exigentes.
La EC480D está diseñada para movimiento de tierras a gran escala, explotación de canteras y proyectos de infraestructura. Con su robusto sistema hidráulico y su amplia cabina, esta máquina ofrece la productividad que se espera de los estándares de ingeniería de Volvo.
- Año: 2014
- Modelo: Volvo EC480D
- Ubicación: Shandong, China
- Apta para excavación pesada y manipulación de materiales
- Disponible para inspección en sitio
Esta excavadora está lista para la evaluación por parte de compradores serios. Contáctenos para coordinar una inspección y analizar los detalles de adquisición según los requerimientos de su flota.
A couple of term choices worth flagging, since they affect search visibility for Spanish-language buyers: - **"maquinaria de trabajo pesado"** is the common marketplace phrasing in LatAm listings; Spain-based buyers more often write "maquinaria pesada". I used the first in the opening line to avoid repetition. - **"manipulación de materiales"** vs. **"manejo de materiales"** — the former reads better in Spain, the latter in Mexico/Colombia/Chile. Swap it if your traffic skews to a specific market. - Keep **"excavadora"** over "excavadora hidráulica" in the `| Especificaciones | Valor |
|---|---|
| No. | 1161475 |
| Tonnage (tons) | 48 |
| Working weight (kg) | 47,900-50,500 |
| Bucket capacity (m³) | 1.77-3.80 |
| Boom length (mm) | 7 |
| Rod length (mm) | 4.8 |
| Country of origin | Korea |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo VOLVO_D13-T4(A) |
| Rated power (kw/rpm) | 245 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 131*158 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 12.8 |
| Working form | Meets European Stage IIIB emission requirements |
| Ground specific pressure (Kpa) | 73.7(700mm) |
| Rotation speed (rpm) | 8.8 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 285/310.6 |
| Rod digging force (kN) | 251 |
| Travel speed (km/h) | 3.1-5.2 |
| Rotary hydraulic motor type | Piston type |
| Type of walking hydraulic motor | Piston type |
| Maximum flow of main pump (l/min) | 2*358 |
| Traveling Hydraulic Circuit (Mpa) | 32.4 |
| Rotary Hydraulic Circuit (Mpa) | 25.8 |
| Main pump type | Piston type |
| Working Hydraulic Circuit (Mpa) | 32.4/35.3 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1*165*1330 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1*190*1850 |
| Boom cylinders - Number × diameter × stroke (mm) | 2*165*1590 |
| Fuel Tank (L) | 685 |
| Hydraulic Tank (L) | 270 |
| Engine Oil changes (L) | 42 |
| Coolant (L) | 60 |
| Hydraulic System (L) | 525 |
| Total transport length (mm) | 12140 |
| Total transport width (mm) | 3367 |
| Total transport height (mm) | 3790 |
| Full cab height (mm) | 3090 |
| Counterweight ground clearance (mm) | 1385 |
| Minimum ground clearance (mm) | 746 |
| Back end turning radius (mm) | 3800 |
| Total track length (mm) | 5370 |
| Track gauge (mm) | 2890(Extended) |
| Track plate width (mm) | 700 |
| Total track width (mm) | 3590(Extended) |
| Track ground length (mm) | 4370 |
| Maximum digging radius (mm) | 12040 |
| Maximum digging depth (mm) | 7720 |
| Maximum excavation height (mm) | 11010 |
| Maximum unloading height (mm) | 7640 |
| Maximum vertical digging depth (mm) | 7110 |
| Maximum excavation radius of stop surface (mm) | 11810 |
| Boom turning Angle (left/right °) | 183 |
| Maximum effective digging depth (mm) | 7570 |
