Descripción del Producto
Esta excavadora hidráulica XCMG XE135B de 2020 está disponible desde Hebei, China. La máquina cuenta con horas reales e historial operativo verificado. Como excavadora de orugas de tamaño medio dentro de la probada clase de 13 toneladas de XCMG, la XE135B ofrece un rendimiento fiable para movimiento de tierras, excavación de zanjas y aplicaciones generales de construcción.
Especificaciones principales:
- Peso operativo: aproximadamente 13.500 kg
- Motor: diésel, con consumo de combustible eficiente
- Sistema hidráulico diseñado para un control ágil
- Configuración estándar de cuchara y brazo
- Cabina con controles para el operador y buena visibilidad
Los equipos XCMG son reconocidos por su durabilidad en obras exigentes. Esta unidad representa una solución rentable para contratistas que buscan una capacidad de excavación confiable. Inspección bienvenida. Adecuada para uso nacional o exportación internacional.
| Especificaciones | Valor |
|---|---|
| No. | 1162754 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
