Descripción del Producto
Esta excavadora hidráulica XCMG XE225DK del año 2021 representa un excelente valor en el mercado de equipos usados. Ubicada en Sichuan, China, esta máquina ofrece un rendimiento confiable para contratistas y operadores que buscan la probada calidad de XCMG a un precio competitivo.
- Año: 2021
- Modelo: XCMG XE225DK
- Clase de peso operativo: ~22 toneladas
- Bajas horas de operación para el año del modelo
- Condición bien mantenida
- Ubicación actual: Provincia de Sichuan, China
La XE225DK está diseñada para aplicaciones medianas y pesadas, incluyendo movimiento de tierras, trabajos de cimentación y construcción en general. La reputación de XCMG en cuanto a durabilidad y facilidad de mantenimiento convierte a esta unidad en una opción práctica para operaciones que requieren un tiempo de actividad constante. Inspección y apoyo logístico disponibles bajo solicitud.
| Especificaciones | Valor |
|---|---|
| No. | 1104861 |
| Tonnage (tons) | 22 |
| Working weight (kg) | 22100 |
| Bucket capacity (m³) | 1.0-1.2 (1.14) |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4HK1 |
| Rated power (kw/rpm) | 140/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 676/1800 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.3 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.2 |
| Rotation speed (rpm) | 11.8 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 111 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.3/3.0 |
| Fuel Tank (L) | 400 |
| Engine Oil changes (L) | 19.5 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 9625 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4255 |
| Track gauge (mm) | 2390 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9940 |
| Maximum digging depth (mm) | 6680 |
| Maximum excavation height (mm) | 9620 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 5715 |
